| System Function |
- Throughput:Constant 240 photometric tests per
hour, up to 400 T/H with ISE
- Measuring principles:Absorbance photometry, Turbidimetry
- Measuring principles:Absorbance photometry, turbidimetry, ion selective electrode technology
- Methodology: End-point, Fixed-time, Kinetic, optional ISE, Single/Double reagent chemistries, Mono-chromatic / bi-chromatic
|
| Reaction System |
- Reaction tray: 80 reusable cuvettes
- Reaction volume: 100~360μL
- Reaction temperature : 37℃ ± 0.1℃
- Cuvette Washing: Washing station with pre-warmed detergent and de-ionized water
|
| Optical System |
- Light Source : Halogen-tungsten lamp
- Wavelength:12 wavelengths, 340nm, 380nm, 412nm, 450nm, 505nm, 546nm, 570nm, 605nm,
660nm, 700nm, 740nm, 800nm/li>
- Absorbance range:0~3.5Abs, resolution 0.0001Abs
- Stray Light: :4.9Abs
|
| Control and Calibration |
- Calibration mode: K factor, Linear (two points and multi-points), Logit-Log 4P, Logit-Log 5P,
Spline, Exponential, Polynomial, Parabola, Logit-Log3P, Broken line One key calibrator import function
- Control rules:Westgard multi-rule, Levey-Jennings, Cumulative sum check, Twin plot
|
| Operation Unit |
- Windows 10
- Interface :RS-232
|
| ISE Module (optional) |
|
| Working Conditions |
- Power Supply:200~240V, 50/60Hz, ≤1300VA or 100~130V, 60Hz, ≤1300VA
- Temperature:15~30°C
- Dimension :860 mm (length) × 660 mm (depth) × 550 mm (height)
- Weigh :115 kg
- Water Consumption:≤6.5 L/H
|
